- Frame building
- Automotive components & trims
|Weight - Kg/m||3.82|
|Metric Size||152.4 mm x 76.2 mm x 6.35 mm|
|Leg Height||3 in (76.2 mm)|
|Base Width||6 in (152.4 mm)|
|Thickness||1/4 in (6.35 mm)|
|Proof Stress||260 Min MPa|
|Tensile Strength||210 MPa|
|Shear Strength||84 to 220 MPa|
|Elongation||8 Min %|
|Melting Point||555 °C|
|Thermal Expansion||24 x10^-6 /K|
|Modulus of Elasticity||70 GPa|
|Thermal Conductivity||180 W/m.K|
|Electrical Resistivity||0.038 x10^-6 Ω .m|
|Workability - Cold||Good|
|Weldability - Gas||Good|
|Weldability - Arc||Good|
|Weldability - Resistance||Good|
METAL HOW YOU WANT IT
Bar Cutting - We specialise in short lead times and high volume production. To achieve this we use a range of CNC controlled twin pillar type bar saws, cutting to a maximum diameter of 12". We also have the facility to cut tubes and sections (Close tolerances available upon request).
Sheet Guillotining - High capacity hydraulic shearing to close tolerances. Maximum thickness 6mm for aluminium products. A temporary plastic coating will be applied to all of our sheet products prior to cutting, to ensure a scratch-free, clean surface. This coating is easy to peel off once you're ready to put the material in place.
Plate Sawing - Blanks cut to customer requirements on a +2mm/ -0mm tolerance. High volume production capabilities and short lead times are available. Currently we offer up to 4" (101.6mm) in thickness, with a maximum length 2500mm. Please note we stock all common commercial grades and speciality cast tooling plate. Any requirements outside of our standard offering, please feel free to email our sales team.
